MERITSUN Brand lithium li ion battery cell ifr factory
Model:
ICR18650 3.7V 2400mAh
Rated Voltage (V):
3.7
Rated Capacity (Ah):
2400mAh
Supply Ability:
500000 Pieces per Month
MOQ:
10
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Approx Dimension (mm):
18650
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Company Advantages
1. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity. Owing to its various quality attributes, provided lithium ion battery cells is highly appreciated by MERITSUN clients.
2. MeriTech Power Co.,Ltd.'s customer service always works on a professional level. The weight of the product is about 40% of the weight of a comparable lead-acid battery
3. Strong reliability is one of the features of the product. Our product array is extensively appreciated among our prestigious clients for their unique features such as optimum performance, longer service life and li ion battery cell,3.7 volt rechargeable lithium ion battery.
4. The installation of 18650 battery cell system is much more convenient than other equipment. It is produced in strict accordance with the UL standard
5. This high drain battery gives a simple modernistic look which enhances the beauty of your 18650 rechargeable lithium ion battery. The charge rate of the product is strong, shortening the charge time efficiently
![]()
![]()
1. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity. Owing to its various quality attributes, provided lithium ion battery cells is highly appreciated by MERITSUN clients.
2. MeriTech Power Co.,Ltd.'s customer service always works on a professional level. The weight of the product is about 40% of the weight of a comparable lead-acid battery
3. Strong reliability is one of the features of the product. Our product array is extensively appreciated among our prestigious clients for their unique features such as optimum performance, longer service life and li ion battery cell,3.7 volt rechargeable lithium ion battery.
4. The installation of 18650 battery cell system is much more convenient than other equipment. It is produced in strict accordance with the UL standard
5. This high drain battery gives a simple modernistic look which enhances the beauty of your 18650 rechargeable lithium ion battery. The charge rate of the product is strong, shortening the charge time efficiently
Product Description
/ For more details, please contact us！
| NO. | Items | Parameter | Remarks |
| 1 | Rated Capacity | 2400mAh | Discharge:0.2C Cut-off voltage:3.0V |
| Minimum Capacity | 2350mAh | ||
| 2 | Energy | 8.88Wh | |
| 3 | Nominal Voltage | 3.7V | |
| 4 | Open Voltage | ≥3.85V | |
| 5 | Load Voltage | ≥ 3.6V | 10Ω |
| 6 | Cycle Life | 500~1000 times | |
| 7 | Internal Impedance | ≤50mΩ | AC 1KHz after 50% charge |
| 8 | Charge voltage | 4.2V | |
| 9 | Standard charge current | 480mA | |
| 10 | Max charge current | 2400mA | |
| 11 | Standard discharge current | 480mA | |
| 12 | Max Discharge current | 3600mA | |
| 13 | Discharge cut-off voltage | 3.0V | |
| 14 | Operating Temperature | 0~+45℃ | Charge |
| -20~+60℃ | Discharge | ||
| 15 | Storage temperature for a long time | -20~25℃ | |
| 16 | Weight | 45±1g | |
| 17 | Dimensions-Diameter | 18.3±0.2mm | |
| Dimensions-Height | 65.3±0.2mm |
The Lithium Battery Cell Characteristic Curve , Please Refer To:
The Battery Advantages and Cells Consistency Countermeasures for
18650 Battery, Lithium Battery, Lipo Battery, Li-ion battery, LiFePO4 Battery,
Rechargeable Lithium ion Battery, Lithium Polymer Battery,
Lithium iron Phosphate Battery
The Battery Safety Assurance and Low Self Discharge for 18650 Battery, Lithium Battery,
Lipo Battery, Li-ion battery, LiFePO4 Battery, Rechargeable Lithium ion Battery,
Lithium Polymer Battery, Lithium iron Phosphate Battery
