latest lifepo4 battery pack supplier for villa
1. MERITSUN lithium ion battery pack has to be tested by an independent test laboratory that must provide proof that the materials meet the requirements of the storage battery industry. Using LiFePO4 along with the integrated BMS, the product features overcharge and discharge protection
2. Except for its good quality, our lifepo4 battery pack is also famous among customers for its service. The product with a long service life can be used for more than 8 years
3. MERITSUN delivers high performance products that are cost-effective, customer-need specific. It is packed with high-quality and sturdy packages
Electrical Characteristics | Nominal Voltage | 12.8V (12V) |
Nominal Capacity | 200Ah | |
Energy | 2560Wh | |
Internal Resistance | ≤180mΩ | |
Cycle Life | >4000 cycles | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @1C | |
Standard Charge | Charge Voltage | 14.6±0.2V |
Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | |
Charger Current | 60A | |
Max. Charge Current | 80A | |
Charge Cut-off Voltage | 15.6V±0.2V | |
Standard Discharge | Continuous Current | 60A |
Max. Pulse Current | 350A(<10s) | |
Discharge Cut-off Voltage | 8V | |
Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | 3.2V10Ah 4S20P |
Plastic Case | ABS | |
Dimensions (in./mm.) | 485*170*245mm | |
Weight (lbs./kg.) | 25kg | |
Terminal | / | |
Protocol (optional) | / | |
SOC (optional) | / |
MeriTech is focusing on new energy, Global market changes of battery, Through market research to constant understand customers needs in order to build a perfect service network,Own many experienced engineers and technicians, to provide comprehensive, in-depth, quickly and attentive service for you. We could response your request immediately.
MeriTech Power Specialist will estimate your power needs, identify potential problem areas and recommend a cost-effective solution. What you'll get:
1. The global optimum acquisition price for any required hardware
2. Installation considerations
3. Ongoing support options
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. has been concentrating on the business of lifepo4 battery pack . We have earned the necessary qualifications for our business. The quality for our lifepo4 battery 12v 100ah is so great that you can definitely rely on.
2. The quality of our lifepo4 battery 12v still keeps unsurpassed in China.
3. Whenever there is any problems for our lithium battery price , you can feel free to ask our professional technician for help. Remembering the mission of 24v lifepo4 battery is a must in MERITSUN. Welcome to visit our factory!
