MERITSUN, the Best Lithium Energy Solution Provider.

vrla tubular deep MERITSUN Brand vrla gel battery factory

Model:

Tubular Gel - OPzV Battery Series

Rated Voltage (V):

Rated Capacity (Ah):

200~3000

Supply Ability:

500000 Pieces per Month

Payment:

L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal

Certificate:

ISO, CE, RoHS, TLC, TUV, IEC, and so on

Please:

click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.

Inquiry

Application Scope

Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system.'s battery energy storage system is widely applicable in the Manufacturing Electrical Equipment & Supplies Batteries industry.Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. always gives priority to customers and services. With a great focus on customers, we strive to meet their needs and provide optimal solutions.With a focus on product quality, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. selects safe and eco-friendly raw materials and adopts fine process to produce battery solutions. They are safe, practical and well-designed with resistance to corrosion, moisture, oxidation, and high temperature. They can be applied in most situations.

Company Advantages
1. It is of extremely low self-discharge rate and can be left unused for a longer time. MERITSUN Battery Solutionprovides you with a full range of technical support and good after-sale service.
2. Production practice shows that opzv battery is more practical in vrla gel battery with good effect, long service life and low cost. It can be widely applied in diverse areas ranging from small appliances and IT devices
3. MeriTech Power Co.,Ltd.'s product performance is stable, price is reasonable and after-sales service good. The product with a long service life can be used for more than 8 years. The product with a long service life can be used for more than 8 years

❈ Product Features

★ General Features：

◪1. Completely sealing throughout the batteries life.
◪2. Service life up to 18-20 years in continuous float operation down to approx 80% capacity.
◪3. Gel electrolyte.
◪4. Low gassing thanks to antimony-free alloy and internal oxygen recombination.
◪5. Minimum space required and room requirements are minimal e.g. no washing facilities needed, ventilation requirements are minimal.
◪6. Easy to move and handle.
◪7. Easy install using cable connectors with insulated terminal covers.
◪8. Ready for immediate use without further commissioning work.
◪9. Can be supplied as a standard vertical installation or by special request, for a horizontal installation.
◪10. Very low self-discharge<50% of rated capacity in 2 years at 20 ℃ ambient temperature.
◪11. High cyclic ability over 600 cycles when discharged at 10 hour rate to an end voltage of 1.8Volt/cell at 20℃ .
◪12. Deep discharge protected, a load can be connected to the battery for up to 4 weeks.
◪13. No internal short circuits possible due to the gel structure.
◪14. No acid stratification, so no equalizing charge necessary.

❈ Typical Applications

Telecommunications	Large UPS and computer back-up	Railway signalling
Emergency lighting systems	Radio and cellular telephone relay stations	Standby power
Process and control engineering	Maritime standby power on ships and ashore	Buoy lighting
Power stations, Conventional power stations, alternative power (solar, wind)

❈ Product Specification

Model	Rated Voltage (V)	Rated Capacity (Ah)	Approx Dimension								Approx Weight		Terminal Type
			Length		Width		Height		Total Height		Approx Weight
			mm	inch	mm	inch	mm	inch	mm	inch	kg	lbs
OPzV200-2	2	200	103	4.06	206	8.11	355	13.98	390	15.35	18.0	39.7	T11
OPzV250-2	2	250	124	4.88	206	8.11	355	13.98	390	15.35	22.0	48.5	T11
OPzV300-2	2	300	145	5.71	206	8.11	355	13.98	390	15.35	26.0	57.3	T11
OPzV350-2	2	350	124	4.88	206	8.11	471	18.54	506	19.92	29.0	63.9	T11
OPzV420-2	2	420	145	5.71	206	8.11	471	18.54	506	19.92	34.0	74.9	T11
OPzV490-2	2	490	166	6.54	206	8.11	471	18.54	506	19.92	39.0	86.0	T11
OPzV600-2	2	600	145	5.71	206	8.11	646	25.43	681	26.81	46.0	101.4	T11
OPzV800-2	2	800	191	7.52	210	8.27	646	25.43	681	26.81	64.5	142.2	T11
OPzV1000-2	2	1000	233	9.17	210	8.27	646	25.43	681	26.81	78.5	173.0	T11
OPzV1200-2	2	1200	275	10.83	210	8.27	646	25.43	681	26.81	93.0	205.0	T11
OPzV1500-2	2	1500	275	10.83	210	8.27	796	31.34	831	32.72	115.0	253.5	T11
OPzV2000-2	2	2000	399	15.71	214	8.43	772	30.39	807	31.77	155.0	341.6	T11
OPzV2500-2	2	2500	487	19.17	212	8.35	772	30.39	807	31.77	196.0	432.0	T11
OPzV3000-2	2	3000	576	22.68	212	8.35	772	30.39	807	31.77	232.0	511.3	T11

★ Specification subject to change without prior notice.

Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!

Company Features
1. At MeriTech Power Co.,Ltd., high quality opzv battery and professional solutions are provided.
2. MeriTech Power Co.,Ltd. is mainly built for the finished opzs battery job with processing and production base.
3. To promote our better cooperation, MeriTech Power Co.,Ltd. is willing to do more for our customers. Get more info!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
