vrla gel battery vrla deep terminal MERITSUN Brand company
1. MeriTech Power Co.,Ltd. only choose the safe material for manufacturing opzv battery. We offer battery solutions to Solar energy storage system, Telecom Station 48V system, 12 or 24V Boat and RV energy systems, etc
2. We adopt oxygen recombination technology. the specifications of opzs battery,vrla gel battery can be customized.
3. The opzs batterie can be adjusted very precisely with the gel batteries for sale that is mounted on it. With high voltage and low self-discharge, our products are environmentally-friendly.
4. The adoption of sealed gel battery endow agm vrla battery with higher performance and price ratio. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises
5. Made-up making utilization of top-grade basic material along with contemporary amenities, these offered 12v gel battery are in tandem with the market defined guidelines and quality standards. We are dedicated to manufacturing and designing LiFePO4 and lithium cells
❈ Product Features
★ General Features：
◪1. Completely sealing throughout the batteries life.
◪2. Service life up to 18-20 years in continuous float operation down to approx 80% capacity.
◪3. Gel electrolyte.
◪4. Low gassing thanks to antimony-free alloy and internal oxygen recombination.
◪5. Minimum space required and room requirements are minimal e.g. no washing facilities needed, ventilation requirements are minimal.
◪6. Easy to move and handle.
◪7. Easy install using cable connectors with insulated terminal covers.
◪8. Ready for immediate use without further commissioning work.
◪9. Can be supplied as a standard vertical installation or by special request, for a horizontal installation.
◪10. Very low self-discharge<50% of rated capacity in 2 years at 20 ℃ ambient temperature.
◪11. High cyclic ability over 600 cycles when discharged at 10 hour rate to an end voltage of 1.8Volt/cell at 20℃ .
◪12. Deep discharge protected, a load can be connected to the battery for up to 4 weeks.
◪13. No internal short circuits possible due to the gel structure.
◪14. No acid stratification, so no equalizing charge necessary.
❈ Typical Applications
| Telecommunications | Large UPS and computer back-up | Railway signalling |
| Emergency lighting systems | Radio and cellular telephone relay stations | Standby power |
| Process and control engineering | Maritime standby power on ships and ashore | Buoy lighting |
| Power stations, Conventional power stations, alternative power (solar, wind) | ||
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
OPzV200-2 | 2 | 200 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 18.0 | 39.7 | T11 |
OPzV250-2 | 2 | 250 | 124 | 4.88 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 22.0 | 48.5 | T11 |
OPzV300-2 | 2 | 300 | 145 | 5.71 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 26.0 | 57.3 | T11 |
OPzV350-2 | 2 | 350 | 124 | 4.88 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 29.0 | 63.9 | T11 |
OPzV420-2 | 2 | 420 | 145 | 5.71 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 34.0 | 74.9 | T11 |
OPzV490-2 | 2 | 490 | 166 | 6.54 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 39.0 | 86.0 | T11 |
OPzV600-2 | 2 | 600 | 145 | 5.71 | 206 | 8.11 | 646 | 25.43 | 681 | 26.81 | 46.0 | 101.4 | T11 |
OPzV800-2 | 2 | 800 | 191 | 7.52 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 64.5 | 142.2 | T11 |
OPzV1000-2 | 2 | 1000 | 233 | 9.17 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 78.5 | 173.0 | T11 |
OPzV1200-2 | 2 | 1200 | 275 | 10.83 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 93.0 | 205.0 | T11 |
OPzV1500-2 | 2 | 1500 | 275 | 10.83 | 210 | 8.27 | 796 | 31.34 | 831 | 32.72 | 115.0 | 253.5 | T11 |
OPzV2000-2 | 2 | 2000 | 399 | 15.71 | 214 | 8.43 | 772 | 30.39 | 807 | 31.77 | 155.0 | 341.6 | T11 |
OPzV2500-2 | 2 | 2500 | 487 | 19.17 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 196.0 | 432.0 | T11 |
OPzV3000-2 | 2 | 3000 | 576 | 22.68 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 232.0 | 511.3 | T11 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MERITSUN is an integrated opzv battery contractor integrating design, procurement and development.
2. Call Now! In Order To Meet The Market Demand, MERITSUN Will Continually Develop New opzs battery, vrla gel battery, opzs batterie. Please See More Information On Our Website.
3. MERITSUN aims to be an international agm vrla battery exporter. Get more info!
