MERITSUN, the Best Lithium Energy Solution Provider.

vrla gel battery telecom opzv battery MERITSUN Brand

Model:

Deep Cycle Battery Series

Rated Voltage (V):

2V, 6V, 12V

Rated Capacity (Ah):

3.5~3000

Supply Ability:

500000 Pieces per Month

Payment:

L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal

Certificate:

ISO, CE, RoHS, TLC, TUV, IEC, and so on

Please:

click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.

Inquiry

Product Comparison

battery solutions is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.battery solutions produced by Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. are of safety, good design, easy installation, and wide applications. In the practical application, they effectively guarantee the stable operation of the power system as well as reduce the operating cost of the system. They are favored by many customers with high economic value.Compared with other products in the same category, battery solutions has the following competitive advantages.

Company Advantages
1. opzv battery is of vrla gel battery with decent detail. The weight of the product is about 40% of the weight of a comparable lead-acid battery
2. Widely used in opzs batterie, these opzs battery are presented to patrons in customized form. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
3. MeriTech Power Co.,Ltd. has formulated a strict quality control system and the operation flow. The product with a long service life can be used for more than 8 years

❈ Product Features

★ General Features：

◪1. Using oxygen recombination technology: maintenance-free
◪2. Special grid alloy: less gassing, less self-discharging
◪3. For longer cycle life: special paste formula, over dimensioned negative plate, optimised manufacturing process , additives for deep discharge
◪4. Thermal management system (optional)
◪5. Special anti-vibration design (optional)
◪6. High quality AGM separator: extend cycle life
◪7. ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)

❈ Typical Applications

Electric tools	Portable apparatus, lights and instruments	Portable power
Vehicle in place of walking	Electric toys	Wheelchairs
Lawn mowers	Illumination light	Medical equipments
Golf trolleys and golf cart	Fire alarms

❈ Product Specification

Model	Rated Voltage (V)	Rated Capacity (Ah)	Approx Dimension								Approx Weight		Terminal Type
			Length		Width		Height		Total Height		Approx Weight
			mm	inch	mm	inch	mm	inch	mm	inch	kg	lbs
GD100-2	2	100	170	6.69	72	2.83	205	8.07	212	8.35	5.75	12.68	T6
GD200-2	2	200	170	6.69	110	4.33	328	12.9	350	13.78	12.0	26.46	T11
GD300-2	2	300	170	6.69	150	5.91	328	12.9	350	13.78	16.8	37.04	T11
GD400-2	2	400	210	8.27	175	6.89	330	13.0	350	13.78	22.4	49.38	T11
GD500-2	2	500	240	9.45	175	6.89	330	13.0	350	13.78	26.7	58.86	T11
GD600-2	2	600	300	11.81	175	6.89	330	13.0	350	13.78	34.0	74.96	T11
GD800-2	2	800	410	16.14	175	6.89	330	13.0	350	13.78	48.2	106.3	T11
GD1000-2	2	1000	475	18.70	175	6.89	328	12.9	350	13.78	55.6	122.6	T11
GD1500-2	2	1500	403	15.87	354	13.94	339	13.4	350	13.78	94.0	207.2	T11
GD2000-2	2	2000	490	19.29	350	13.78	339	13.4	350	13.78	112.9	248.9	T11
GD3000-2	2	3000	712	28.03	350	13.78	339	13.4	350	13.78	169.1	372.8	T11
GD5.6-6	6	5.6	70	2.76	47	1.85	100	3.94	103	4.17	0.93	20.5	T1/T2
GD13-6	6	13	151	5.94	51	2.01	94	3.70	100	3.94	2.03	4.52	T1/T2
GD3.5-12	12	3.5	134	5.28	67	2.64	60.5	2.38	66.5	2.62	1.36	3.00	T1
GD5.6-12	12	5.6	90	3.54	70	2.76	101	3.98	107	4.21	1.74	3.84	T1/T2
GD7.2-12	12	7.2	151	5.94	65	2.56	94.5	3.72	99.5	3.92	2.50	5.51	T1/T2
GD8-12	12	8	151	5.94	65	2.56	94.5	3.72	99.5	3.92	2.45	5.40	T1/T2
GD12-12	12	12	151	5.94	98	3.86	95	3.74	101	3.98	4.00	8.82	T1/T2
GD17-12	12	17	181	7.13	76	2.99	167	6.57	167	6.58	5.90	13.01	T3
GD24-12	12	24	165	6.50	125	4.92	175	6.89	182	7.17	8.40	18.52	T3/T10/T12
GD33-12	12	33	195	7.68	130	5.12	155	6.10	180	7.09	9.60	21.16	T5/T6/T12
GD38-12	12	38	197	7.76	165	6.50	176	6.93	182	7.17	12.7	27.99	T5/T6/T12
GD55-12	12	55	231	9.09	139	5.47	208	8.19	225	8.86	14.7	32.41	T6/T9/T14
GD65-12	12	65	348	13.70	166	6.54	178	7.01	178	7.01	19.5	42.99	T6
GD80-12	12	80	348	13.70	166	6.54	178	7.01	178	7.01	21.6	47.62	T6
GD90-12	12	90	306	12.05	168	6.61	210	8.27	230	9.06	25.0	55.12	T6/T9
GD100-12A	12	100	329	12.95	171	6.73	214	8.43	220	8.66	29.5	65.04	T11
GD100-12B	12	100	407	16.02	174	6.85	208	8.19	233	9.17	31.0	68.34	T11
GD120-12	12	120	407	16.02	174	6.85	208	8.19	233	9.17	32.4	71.43	T11
GD150-12	12	150	483	19.02	170	6.69	239	9.41	240	9.45	41.5	91.49	T11
GD200-12	12	200	522	20.55	239	9.41	218	8.58	224	8.82	56.2	123.9	T11
GD250-12	12	250	522	20.55	268	10.55	218	8.58	226	8.90	71.0	156.5	T11

★ Specification subject to change without prior notice.

Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!

Company Features
1. We have carved niche in the industry by offering an extensive range of opzv battery.
2. Major breakthrough in producing finest opzs battery has been made in MERITSUN.
3. MeriTech Power Co.,Ltd. has always pursued excellence and professionalism in the agm vrla battery field. Contact!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
