vrla gel battery flooded opzv vrla MERITSUN Brand opzv battery
1. The product is produced under the principle of environmental protection. Owing to its various quality attributes, provided vrla gel battery is highly appreciated by MERITSUN clients.
2. MeriTech Power Co.,Ltd.'s customer service always works on a professional level. The product is designed with a protection circuit which can totally ensure the safety of users
3. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity. Stable performance and long lifespan of opzv battery,opzs batterie is guaranteed.
4. It can be used within a wider temperature range from -20℃ to 65℃. Our offered opzs battery,gel batteries for sale are widely recognized by our clients for their high quality and sealed gel battery.
5. Whatever products our agm vrla battery is used in, it works well. The charge rate of the product is strong, shortening the charge time efficiently
❈ Product Features
★ General Features：
◪1. Using oxygen recombination technology: maintenance-free
◪2. Special grid alloy: less gassing, less self-discharging
◪3. For longer cycle life: special paste formula, over dimensioned negative plate, optimised manufacturing process , additives for deep discharge
◪4. Thermal management system (optional)
◪5. Special anti-vibration design (optional)
◪6. High quality AGM separator: extend cycle life
◪7. ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)
❈ Typical Applications
| Electric tools | Portable apparatus, lights and instruments | Portable power |
| Vehicle in place of walking | Electric toys | Wheelchairs |
| Lawn mowers | Illumination light | Medical equipments |
| Golf trolleys and golf cart | Fire alarms | |
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
GD100-2 | 2 | 100 | 170 | 6.69 | 72 | 2.83 | 205 | 8.07 | 212 | 8.35 | 5.75 | 12.68 | T6 |
GD200-2 | 2 | 200 | 170 | 6.69 | 110 | 4.33 | 328 | 12.9 | 350 | 13.78 | 12.0 | 26.46 | T11 |
GD300-2 | 2 | 300 | 170 | 6.69 | 150 | 5.91 | 328 | 12.9 | 350 | 13.78 | 16.8 | 37.04 | T11 |
GD400-2 | 2 | 400 | 210 | 8.27 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 22.4 | 49.38 | T11 |
GD500-2 | 2 | 500 | 240 | 9.45 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 26.7 | 58.86 | T11 |
GD600-2 | 2 | 600 | 300 | 11.81 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 34.0 | 74.96 | T11 |
GD800-2 | 2 | 800 | 410 | 16.14 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 48.2 | 106.3 | T11 |
GD1000-2 | 2 | 1000 | 475 | 18.70 | 175 | 6.89 | 328 | 12.9 | 350 | 13.78 | 55.6 | 122.6 | T11 |
GD1500-2 | 2 | 1500 | 403 | 15.87 | 354 | 13.94 | 339 | 13.4 | 350 | 13.78 | 94.0 | 207.2 | T11 |
GD2000-2 | 2 | 2000 | 490 | 19.29 | 350 | 13.78 | 339 | 13.4 | 350 | 13.78 | 112.9 | 248.9 | T11 |
GD3000-2 | 2 | 3000 | 712 | 28.03 | 350 | 13.78 | 339 | 13.4 | 350 | 13.78 | 169.1 | 372.8 | T11 |
GD5.6-6 | 6 | 5.6 | 70 | 2.76 | 47 | 1.85 | 100 | 3.94 | 103 | 4.17 | 0.93 | 20.5 | T1/T2 |
GD13-6 | 6 | 13 | 151 | 5.94 | 51 | 2.01 | 94 | 3.70 | 100 | 3.94 | 2.03 | 4.52 | T1/T2 |
GD3.5-12 | 12 | 3.5 | 134 | 5.28 | 67 | 2.64 | 60.5 | 2.38 | 66.5 | 2.62 | 1.36 | 3.00 | T1 |
GD5.6-12 | 12 | 5.6 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | 1.74 | 3.84 | T1/T2 |
GD7.2-12 | 12 | 7.2 | 151 | 5.94 | 65 | 2.56 | 94.5 | 3.72 | 99.5 | 3.92 | 2.50 | 5.51 | T1/T2 |
GD8-12 | 12 | 8 | 151 | 5.94 | 65 | 2.56 | 94.5 | 3.72 | 99.5 | 3.92 | 2.45 | 5.40 | T1/T2 |
GD12-12 | 12 | 12 | 151 | 5.94 | 98 | 3.86 | 95 | 3.74 | 101 | 3.98 | 4.00 | 8.82 | T1/T2 |
GD17-12 | 12 | 17 | 181 | 7.13 | 76 | 2.99 | 167 | 6.57 | 167 | 6.58 | 5.90 | 13.01 | T3 |
GD24-12 | 12 | 24 | 165 | 6.50 | 125 | 4.92 | 175 | 6.89 | 182 | 7.17 | 8.40 | 18.52 | T3/T10/T12 |
GD33-12 | 12 | 33 | 195 | 7.68 | 130 | 5.12 | 155 | 6.10 | 180 | 7.09 | 9.60 | 21.16 | T5/T6/T12 |
GD38-12 | 12 | 38 | 197 | 7.76 | 165 | 6.50 | 176 | 6.93 | 182 | 7.17 | 12.7 | 27.99 | T5/T6/T12 |
GD55-12 | 12 | 55 | 231 | 9.09 | 139 | 5.47 | 208 | 8.19 | 225 | 8.86 | 14.7 | 32.41 | T6/T9/T14 |
GD65-12 | 12 | 65 | 348 | 13.70 | 166 | 6.54 | 178 | 7.01 | 178 | 7.01 | 19.5 | 42.99 | T6 |
GD80-12 | 12 | 80 | 348 | 13.70 | 166 | 6.54 | 178 | 7.01 | 178 | 7.01 | 21.6 | 47.62 | T6 |
GD90-12 | 12 | 90 | 306 | 12.05 | 168 | 6.61 | 210 | 8.27 | 230 | 9.06 | 25.0 | 55.12 | T6/T9 |
GD100-12A | 12 | 100 | 329 | 12.95 | 171 | 6.73 | 214 | 8.43 | 220 | 8.66 | 29.5 | 65.04 | T11 |
GD100-12B | 12 | 100 | 407 | 16.02 | 174 | 6.85 | 208 | 8.19 | 233 | 9.17 | 31.0 | 68.34 | T11 |
GD120-12 | 12 | 120 | 407 | 16.02 | 174 | 6.85 | 208 | 8.19 | 233 | 9.17 | 32.4 | 71.43 | T11 |
GD150-12 | 12 | 150 | 483 | 19.02 | 170 | 6.69 | 239 | 9.41 | 240 | 9.45 | 41.5 | 91.49 | T11 |
GD200-12 | 12 | 200 | 522 | 20.55 | 239 | 9.41 | 218 | 8.58 | 224 | 8.82 | 56.2 | 123.9 | T11 |
GD250-12 | 12 | 250 | 522 | 20.55 | 268 | 10.55 | 218 | 8.58 | 226 | 8.90 | 71.0 | 156.5 | T11 |
★ Specification subject to change without prior notice.
