vrla gel battery cycle gel opzv battery vrla company
1. Its long cycle life with over 2000 cycles helps owners reduce replacement cost. We have carved a niche in the industry by manufacturing and supplying a wide gamut of vrla gel battery.
2. The product with a long service life can be used for more than 8 years. Compared with the other similar opzs batterie, opzv battery,gel batteries for sale has a lot of advantages, such as sealed gel battery.
3. Strong reliability is one of the features of the product. MERITSUN can make a guarantee for the quality of opzs battery,vrla battery manufacturers.
❈ Product Features
★ General Features：
◪1. Completely sealing throughout the batteries life.
◪2. Service life up to 18-20 years in continuous float operation down to approx 80% capacity.
◪3. Gel electrolyte.
◪4. Low gassing thanks to antimony-free alloy and internal oxygen recombination.
◪5. Minimum space required and room requirements are minimal e.g. no washing facilities needed, ventilation requirements are minimal.
◪6. Easy to move and handle.
◪7. Easy install using cable connectors with insulated terminal covers.
◪8. Ready for immediate use without further commissioning work.
◪9. Can be supplied as a standard vertical installation or by special request, for a horizontal installation.
◪10. Very low self-discharge<50% of rated capacity in 2 years at 20 ℃ ambient temperature.
◪11. High cyclic ability over 600 cycles when discharged at 10 hour rate to an end voltage of 1.8Volt/cell at 20℃ .
◪12. Deep discharge protected, a load can be connected to the battery for up to 4 weeks.
◪13. No internal short circuits possible due to the gel structure.
◪14. No acid stratification, so no equalizing charge necessary.
❈ Typical Applications
| Telecommunications | Large UPS and computer back-up | Railway signalling |
| Emergency lighting systems | Radio and cellular telephone relay stations | Standby power |
| Process and control engineering | Maritime standby power on ships and ashore | Buoy lighting |
| Power stations, Conventional power stations, alternative power (solar, wind) | ||
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
OPzV200-2 | 2 | 200 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 18.0 | 39.7 | T11 |
OPzV250-2 | 2 | 250 | 124 | 4.88 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 22.0 | 48.5 | T11 |
OPzV300-2 | 2 | 300 | 145 | 5.71 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 26.0 | 57.3 | T11 |
OPzV350-2 | 2 | 350 | 124 | 4.88 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 29.0 | 63.9 | T11 |
OPzV420-2 | 2 | 420 | 145 | 5.71 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 34.0 | 74.9 | T11 |
OPzV490-2 | 2 | 490 | 166 | 6.54 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 39.0 | 86.0 | T11 |
OPzV600-2 | 2 | 600 | 145 | 5.71 | 206 | 8.11 | 646 | 25.43 | 681 | 26.81 | 46.0 | 101.4 | T11 |
OPzV800-2 | 2 | 800 | 191 | 7.52 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 64.5 | 142.2 | T11 |
OPzV1000-2 | 2 | 1000 | 233 | 9.17 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 78.5 | 173.0 | T11 |
OPzV1200-2 | 2 | 1200 | 275 | 10.83 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 93.0 | 205.0 | T11 |
OPzV1500-2 | 2 | 1500 | 275 | 10.83 | 210 | 8.27 | 796 | 31.34 | 831 | 32.72 | 115.0 | 253.5 | T11 |
OPzV2000-2 | 2 | 2000 | 399 | 15.71 | 214 | 8.43 | 772 | 30.39 | 807 | 31.77 | 155.0 | 341.6 | T11 |
OPzV2500-2 | 2 | 2500 | 487 | 19.17 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 196.0 | 432.0 | T11 |
OPzV3000-2 | 2 | 3000 | 576 | 22.68 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 232.0 | 511.3 | T11 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. is the one of the most advanced and largest opzv battery production base in China.
2. MERITSUN produces opzs battery through modern technology.
3. MeriTech Power Co.,Ltd. is committed to becoming a comprehensive agm vrla battery provider with global influence. Welcome to visit our factory!
