terminal battery opzv battery opzs MERITSUN company
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. has a large number of outstanding professional talents, which lays a solid foundation for the development.
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. is equipped with professional sales and customer service staff. They are able to provide services such as consulting, customization and product selection.
- Looking ahead, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. will run the business which is talent-based, quality-rooted and innovation-driven. We run a modern enterprise management system and improve our comprehensive strength. We are committed to becoming a world-renowned leader in the industry.
- Founded in 1999, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. has always been focusing on manufacturing electric equipment for many years. We have accumulated rich manufacturing experience. We are proficient in the production with exquisite production technology and high production efficiency. At present, we are a high-quality electric equipment supplier in China.
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system.'s battery solutions are not only well received in the domestic market, but also sold well in the overseas market.
1. Now MERITSUN has been coming up with innovations to improve functionality and operational comfort.It can be widely applied in diverse areas ranging from small appliances and IT devices
2. Strong reliability is one of the features of the product. opzv battery,vrla gel battery has good performance and reasonable price.
3. MERITSUN is well-appreciated by customers for its not only the opzs battery but also the service. The product with a long service life can be used for more than 8 years
❈ Product Features
★ General Features：
◪1. Completely sealing throughout the batteries life.
◪2. Service life up to 18-20 years in continuous float operation down to approx 80% capacity.
◪3. Gel electrolyte.
◪4. Low gassing thanks to antimony-free alloy and internal oxygen recombination.
◪5. Minimum space required and room requirements are minimal e.g. no washing facilities needed, ventilation requirements are minimal.
◪6. Easy to move and handle.
◪7. Easy install using cable connectors with insulated terminal covers.
◪8. Ready for immediate use without further commissioning work.
◪9. Can be supplied as a standard vertical installation or by special request, for a horizontal installation.
◪10. Very low self-discharge<50% of rated capacity in 2 years at 20 ℃ ambient temperature.
◪11. High cyclic ability over 600 cycles when discharged at 10 hour rate to an end voltage of 1.8Volt/cell at 20℃ .
◪12. Deep discharge protected, a load can be connected to the battery for up to 4 weeks.
◪13. No internal short circuits possible due to the gel structure.
◪14. No acid stratification, so no equalizing charge necessary.
❈ Typical Applications
| Telecommunications | Large UPS and computer back-up | Railway signalling |
| Emergency lighting systems | Radio and cellular telephone relay stations | Standby power |
| Process and control engineering | Maritime standby power on ships and ashore | Buoy lighting |
| Power stations, Conventional power stations, alternative power (solar, wind) | ||
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
OPzV200-2 | 2 | 200 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 18.0 | 39.7 | T11 |
OPzV250-2 | 2 | 250 | 124 | 4.88 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 22.0 | 48.5 | T11 |
OPzV300-2 | 2 | 300 | 145 | 5.71 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 26.0 | 57.3 | T11 |
OPzV350-2 | 2 | 350 | 124 | 4.88 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 29.0 | 63.9 | T11 |
OPzV420-2 | 2 | 420 | 145 | 5.71 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 34.0 | 74.9 | T11 |
OPzV490-2 | 2 | 490 | 166 | 6.54 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 39.0 | 86.0 | T11 |
OPzV600-2 | 2 | 600 | 145 | 5.71 | 206 | 8.11 | 646 | 25.43 | 681 | 26.81 | 46.0 | 101.4 | T11 |
OPzV800-2 | 2 | 800 | 191 | 7.52 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 64.5 | 142.2 | T11 |
OPzV1000-2 | 2 | 1000 | 233 | 9.17 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 78.5 | 173.0 | T11 |
OPzV1200-2 | 2 | 1200 | 275 | 10.83 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 93.0 | 205.0 | T11 |
OPzV1500-2 | 2 | 1500 | 275 | 10.83 | 210 | 8.27 | 796 | 31.34 | 831 | 32.72 | 115.0 | 253.5 | T11 |
OPzV2000-2 | 2 | 2000 | 399 | 15.71 | 214 | 8.43 | 772 | 30.39 | 807 | 31.77 | 155.0 | 341.6 | T11 |
OPzV2500-2 | 2 | 2500 | 487 | 19.17 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 196.0 | 432.0 | T11 |
OPzV3000-2 | 2 | 3000 | 576 | 22.68 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 232.0 | 511.3 | T11 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MERITSUN is capable of producing high quality opzv battery with its strong technical force.
2. To ensure quality of opzs battery, MeriTech Power Co.,Ltd. introduced a full set of quality control system.
3. By cause of the fundamental principle of being optimistic, MERITSUN intends to be a highly effective agm vrla battery manufacturer. Inquiry!
