telecom Custom opzs opzv battery battery MERITSUN
- Based on the implementation of advanced talent reserve strategy, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. introduces a large number of outstanding technical and management talents. They contribute to our development.
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. can provide quality products for consumers. We also run a comprehensive after-sales service system to solve all kinds of problems in time.
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. intends to be responsible, united, pragmatic and efficient, which is aligned with the corporate value. Customers and services are of great importance to our business. We strive to build an excellent enterprise with a good business reputation and quality services.
- Since the establishment in 1999, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. has continuously refined and summarized the experience in electric equipment manufacturing. Based on rich experience, we have formed a unique standard production mode of electric equipment. We have developed the electric equipment business in a modern way.
- Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system.'s products are only widely praised in the domestic market, but also favored by consumers in the international market.
1. vrla gel battery materials can optimize the performance of opzv battery. It has passed the certification of TLC, TUV, RoHS, and so on
2. opzs battery functions perfectly in the development of the multiple application needs. The product is produced under the principle of environmental protection
3. opzs batterie optimizes the functions of agm vrla battery which also improves the efficiency. The product is designed with a protection circuit which can totally ensure the safety of users
4. MeriTech Power Co.,Ltd. holds open attitude to suggestions for our 12v gel battery from our customers. The product with a long service life can be used for more than 8 years
❈ Product Features
★ General Features：
◪1. Lower self discharge.
◪2. Higher thermal capacity, No thermal runaway will occur
◪3. Superior deep cycle performance.
◪4. Wide operation temperature range.
◪5. Long service life, designed life 15-20 years.
❈ Typical Applications
| Telecommunications | Buoy lighting | Radio and cellular telephone relay stations |
| Emergency lighting systems | Railway signalling | Large UPS and computer back-up |
| alternative power (solar, wind) | Standby power | Maritime standby power on ships and ashore |
| Power stations, Conventional power stations | ||
❈ Product Specification
Type | Model | Rated Voltage | Rated Capacity | Approx Dimension (mm/in) | Approx | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | in | mm | in | mm | in | mm | in | Kg | lbs | ||||
2V | OPzS100-2 | 2 | 100 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 410 | 16.14 | 8.1 | 17.9 |
OPzS150-2 | 2 | 150 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 410 | 16.14 | 10.8 | 23.8 | |
OPzS200-2 | 2 | 200 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 410 | 16.14 | 12.9 | 28.4 | |
OPzS250-2 | 2 | 250 | 124 | 4.88 | 206 | 8.11 | 355 | 13.98 | 410 | 16.14 | 15.4 | 33.9 | |
OPzS300-2 | 2 | 300 | 145 | 5.71 | 206 | 8.11 | 355 | 13.98 | 410 | 16.14 | 18.5 | 40.8 | |
OPzS350-2 | 2 | 350 | 124 | 4.88 | 206 | 8.11 | 471 | 18.54 | 526 | 20.71 | 21.0 | 46.3 | |
OPzS420-2 | 2 | 420 | 145 | 5.71 | 206 | 8.11 | 471 | 18.54 | 526 | 20.71 | 24.5 | 54.0 | |
OPzS490-2 | 2 | 490 | 166 | 6.54 | 206 | 8.11 | 471 | 18.54 | 526 | 20.71 | 28.0 | 61.7 | |
OPzS600-2 | 2 | 600 | 145 | 5.71 | 206 | 8.11 | 646 | 25.43 | 701 | 27.6 | 33.4 | 73.6 | |
OPzS800-2 | 2 | 800 | 191 | 7.52 | 210 | 8.27 | 646 | 25.43 | 701 | 27.6 | 47.0 | 103.6 | |
OPzS1000-2 | 2 | 1000 | 233 | 9.17 | 210 | 8.27 | 646 | 25.43 | 701 | 27.6 | 57.0 | 125.7 | |
OPzS1200-2 | 2 | 1200 | 275 | 10.83 | 210 | 8.27 | 646 | 25.43 | 701 | 27.6 | 67.5 | 148.8 | |
OPzS1500-2 | 2 | 1500 | 275 | 10.83 | 210 | 8.27 | 796 | 31.34 | 851 | 33.5 | 83.5 | 184.1 | |
OPzS2000-2 | 2 | 2000 | 399 | 15.71 | 214 | 8.42 | 772 | 30.39 | 827 | 32.56 | 110.0 | 242.6 | |
OPzS2500-2 | 2 | 2500 | 487 | 19.17 | 212 | 8.35 | 772 | 30.39 | 827 | 32.56 | 139.0 | 306.5 | |
OPzS3000-2 | 2 | 3000 | 576 | 22.68 | 212 | 8.35 | 772 | 30.39 | 827 | 32.56 | 164.5 | 362.7 | |
6V | OPzS200-6 | 6 | 200 | 272 | 10.7 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 35.0 | 77.2 |
OPzS250-6 | 6 | 250 | 381 | 15.0 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 45.0 | 99.2 | |
OPzS300-6 | 6 | 300 | 381 | 15.0 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 49.9 | 110.1 | |
12V | OPzS50-12 | 12 | 50 | 272 | 10.7 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 28.2 | 62.2 |
OPzS100-12 | 12 | 100 | 272 | 10.7 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 38.5 | 84.9 | |
OPzS150-12 | 12 | 150 | 381 | 15.0 | 205 | 8.07 | 337 | 13.27 | 384 | 15.12 | 53.0 | 117.0 | |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. is a lively and enthusiastic manufacturer centered on opzv battery.
2. Advanced technology, high-invested machine & equipment and well-trained workers ensure both high production capability and high quality for MERITSUN.
3. It is essential for MERITSUN to stick to the corporate culture of opzs battery to keep forward. Check now!
