Company Advantages1. MERITSUN home battery system has been evaluated with regard to many aspects. They include flexibility, flexing resistance, colorfastness, hardness & thickness, and slip & fatigue resistance.
2. The product, highly recommended by users, has great market potential. Using LiFePO4 along with the integrated BMS, the product features overcharge and discharge protection
3. Its quality is highly evaluated by authoritative testing organizations. It is very easy to use
4. The performance and quality of the product meet with the industry specification. The charge rate of the product is strong, shortening the charge time efficiently
![rechargeable home battery backup series for TV 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
![rechargeable home battery backup series for TV 12]()
| Models | AI 3K | AI 5K |
| Models |
|
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3KWH | 5KWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO4 Battery |
| AC Output |
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 13.7 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Output Type |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
| Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
|
| Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
|
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan |
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
|
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Solar—Battery—Utility |
![rechargeable home battery backup series for TV 13]()
![rechargeable home battery backup series for TV 14]()
![rechargeable home battery backup series for TV 15]()
![rechargeable home battery backup series for TV 16]()
![rechargeable home battery backup series for TV 17]()
![rechargeable home battery backup series for TV 18]()
![rechargeable home battery backup series for TV 19]()
