Company Advantages1. MERITSUN home battery backup has many innovative and practical designs. The product with a long service life can be used for more than 8 years
2. This product is widely used and has great market potential. The product is produced under the principle of environmental protection
3. home battery backup is said to be the most popular lithium ion home battery due to its battery for home use . The product comes with OEM and ODM availability
4. It's easy to operate for our home battery backup. It is of extremely low self-discharge rate and can be left unused for a longer time
5. The great operation of lithium ion home battery indicates the high performance of home battery backup. Strong reliability is one of the features of the product
![rechargeable home battery backup factory for family 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
| Models | AI 3K | AI 5K |
| Battery |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3kWH | 5kWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO Battery
|
AC Output
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 22 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Multi-purpose Socket×2 |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| MPPT Range | 60V~115V |
Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan
|
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Load Match Mode |
![rechargeable home battery backup factory for family 12]()
![rechargeable home battery backup factory for family 13]()
![rechargeable home battery backup factory for family 14]()
![rechargeable home battery backup factory for family 15]()
![rechargeable home battery backup factory for family 16]()
![rechargeable home battery backup factory for family 17]()
![rechargeable home battery backup factory for family 18]()
![rechargeable home battery backup factory for family 19]()
![rechargeable home battery backup factory for family 20]()
Company Features1. As time goes by, MERITSUN is growing to adapt to the changes of the home battery backup market. When speaking of quality, house power battery is undoubtedly overwhelming to similar products.
2. For its unique lithium ion home battery and finest battery for home use , our home battery backup has become the required goods.
3. With the help of advanced machines, home battery backup is produced in high efficiency and high quality. The principle of "Innovate, Improve, and Breaking through" has become the main strategy for our company to grow. Under this principle, we are seeking new ways to upgrade our products and improve product quality.
