Company Advantages1. The creation of MERITSUN house power battery strictly complies with international electrical principles. It is manufactured conforming CE mark, GE mark, EMC standards, etc. The product with a long service life can be used for more than 8 years
2. People will find that it has a wide range of applications in our daily life. They can find it exists in fields such as telecommunication, navigation, national defenses, etc. It is produced in strict accordance with the UL standard
3. It can continually regulate the skin's microclimate. As the skin gets hot, the heat is absorbed, and as it cools, that heat is released. The weight of the product is about 40% of the weight of a comparable lead-acid battery
4. The product features the desired electrical safety. During its operation, it is less likely to appear problems like discharge, surge current, and current leakage. It is of extremely low self-discharge rate and can be left unused for a longer time
![portable house power battery factory for house2 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
Models | AI 3K | AI 5K |
Battery |
Nominal Voltage [V] | 51.2 |
Voltage Range [V] | 44.8~57.6 |
Capacity | 3kWH | 5kWH |
Max.discharge rate | 0.7C | 0.7C |
Max.charge rate | 0.5C | 0.5C |
Battery Type | LiFePO Battery
|
AC Output
|
Rated Power | 3000VA | 5000VA |
Overload Capacity | 120% (5s) |
200% (100ms) |
Output Voltage | 230Vac±2% |
Output Current | 13.7 A | 22 A |
Rated Frequency | 50/60Hz |
VTHD | 3% |
Transfer Time | <10ms |
Output Wave | Pure Sine Wave |
Output Type | Multi-purpose Socket×2 |
AC Input Voltage Range | 170~280Vac |
AC Input Frequency | 50Hz/60Hz |
Max AC Charge Current(Battery) | 40A | 60A |
PV Input |
Max. PV Power(Recommended) | 3000w | 4000w |
Max. PV Voltage | 145V |
MPPT Range | 60V~115V |
Max PV Charge Current(Battery) | 60A | 80A |
Operating Conditions |
Operating Temperature | 0~55℃ |
Storage Temperature | -15℃~60℃ |
Humidity | 5%~95% |
Cooling Strategy | Fan
|
Weight [kg] | 42 | 60 |
Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
Enclosure Protection Rating | IP31 |
Communication | Wifi(Remote) |
Work Mode |
Solar First | Solar and UPS |
Utility First | UPS and Backup |
Solar—Battery—Utility | Load Match Mode |
![portable house power battery factory for house2 12]()
![portable house power battery factory for house2 13]()
![portable house power battery factory for house2 14]()
![portable house power battery factory for house2 15]()
![portable house power battery factory for house2 16]()
![portable house power battery factory for house2 17]()
![portable house power battery factory for house2 18]()
![portable house power battery factory for house2 19]()
![portable house power battery factory for house2 20]()
Company Features1. The constant development of MERITSUN promotes its position in house power battery industry.
2. Equipped with a wide range of state-of-the-art production facilities, the factory is able to guarantee outstanding product quality, achieve maximum productivity, as well as ensure a high level of production consistency.
3. We insist on professional service and excellent quality. Inquiry!
