Company Advantages1. MERITSUN home battery system will be checked in various parameters. A battery function tester has been used to check its open-circuit voltage, the internal resistance of the cell, and protection level. The product is designed with a protection circuit which can totally ensure the safety of users
2. The increasing popularity shows the favorable market application potential of the products. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
3. The product has a low self-discharge rate. It is not easily affected by the inner or outer temperature, and its chemical components keep stably under low or high temperature. Strong reliability is one of the features of the product
4. The product is of flexibility. Unlike some batteries which need to be placed in the upright position, it can operate in any position and offer good impact tolerance. It is very easy to use
5. The product is less likely to leak. It is finely sealed with good materials which effectively hide its electrolyte inside. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity
![portable home battery backup factory direct supply for home appliances 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
![portable home battery backup factory direct supply for home appliances 12]()
| Models | AI 3K | AI 5K |
| Models |
|
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3KWH | 5KWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO4 Battery |
| AC Output |
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 13.7 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Output Type |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
| Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
|
| Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
|
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan |
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
|
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Solar—Battery—Utility |
![portable home battery backup factory direct supply for home appliances 13]()
![portable home battery backup factory direct supply for home appliances 14]()
![portable home battery backup factory direct supply for home appliances 15]()
![portable home battery backup factory direct supply for home appliances 16]()
![portable home battery backup factory direct supply for home appliances 17]()
![portable home battery backup factory direct supply for home appliances 18]()
![portable home battery backup factory direct supply for home appliances 19]()
