Model:
Front Terminal Battery Series
Rated Voltage (V):
12
Rated Capacity (Ah):
40~200
Supply Ability:
500000 Pieces per Month
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Certificate:
ISO, CE, RoHS, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Inquiry
Company Advantages
1. MeriTech Power Limited is a Turnkey Division of JYC Group. As one of the unique feature, vrla gel battery successfully makes opzs batterie more popular among customers. MeriTech Power Limited is a Turnkey Division of JYC Group
2. MeriTech Power Co.,Ltd., well-known for its superior quality, will provide first-class service. Focusing on smart energy project, we are an innovation pioneer
3. We are dedicated to manufacturing and designing LiFePO4 and lithium cells, MERITSUN Is A China opzv battery, gel batteries for sale Supplier, Who Offers A Variety Of Goods With Professional Service.

❈ Product Features

bg


★ General Features:

  • 1. Specifically ideal for 19 inch or 23 inch power cabinets

  • 2. Front terminals make the installation, maintenance and supervision easy

  • 3. Shield designs protect terminals from short circuit and show good appearance

  • 4. Unique vent valve design: reduce water losing and prevent air/spark going inside

  • 5. Thick plates, special formula of paste and plate making process for a long service life

  • 6. ABS material: increase the strength of battery container (Flame-retardant ABS is optional)


❈ Typical Applications

bg


For standard 19 inch or 23 inch power cabinets
Power station systems
UPS, standby power supply
Network connection equipment of communication system
 Power system of special network or local area network


❈ Product  Specification

bg



Model

Rated

Voltage

(V)

Rated

Capacity

(Ah)

Approx Dimension

Approx

Weight

Terminal

Type

Length

Width

Height

Total Height

mm

inch

mm

inch

mm

inch

mm

inch

kg

lbs

GF40-12

12

40

274

10.79

105

4.13

220

8.66

220

8.66

13.0

28.7

T6

GF50-12

12

50

390

15.35

107

4.21

200

7.87

200

7.87

18.5

40.8

T6

GF70-12

12

70

564

22.20

114

4.49

187

7.36

187

7.36

25.0

55.1

T6

GF75-12

12

75

564

22.20

114

4.49

187

7.36

187

7.36

26.0

57.3

T6

GF90-12

12

90

508

20.00

110

4.33

239

9.41

239

9.41

31.0

68.3

T13

GF92-12

12

92

396

15.59

111

4.37

285

11.22

285

11.22

29.5

65.0

T6

GF100-12A

12

100

396

15.59

111

4.37

285

11.22

285

11.22

33.0

72.8

T6

GF100-12B

12

100

520

20.47

107

4.21

263

10.35

263

10.35

33.0

72.8

T6

GF120-12

12

120

520

20.47

107

4.21

263

10.35

263

10.35

39.5

87.1

T6

GF125-12

12

125

551

21.69

110

4.33

287

11.30

287

11.30

40.5

89.3

T6

GF150-12

12

150

558

21.97

125

4.92

283

11.14

283

11.14

48.0

105.8

T6

GF180-12

12

180

561

22.09

125

4.92

316

12.44

316

12.44

52.0

114.6

T6

GF200-12

12

200

550

21.65

125

4.92

330

12.99

330

12.99

62.0

136.7

T6

★ Specification subject to change without prior notice.
