MERITSUN new lithium battery low temperature supply for streetlight1
Model:
LFP200-12.8, Bluetooth Battery
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Video Display
1. Throughout the manufacturing process of MERITSUN low temp lithium battery , tight tolerances and strict process controls are essential to ensure that there is no contamination, physical damage on the electrodes. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity
2. MeriTech Power Co.,Ltd. has advanced production equipment and perfect quality management system for lithium battery low temperature . The product comes with OEM and ODM availability
3. lithium battery low temperature combines qualities of low temp lithium battery . The product with a long service life can be used for more than 8 years
Electrica Characteristics | Nominal Voltage | 12.8V | ||||
| Nominal Capacity | 100Ah | |||||
| Energy | 1280Wh | |||||
| Internal Resistance | ≤150mΩ | |||||
| Cycle Life | ≥4000 cycles @1C 100%DOD | |||||
| Months Self Discharge | <3% | |||||
| Efficiency of Charge | 100% @0.5C | |||||
| Efficiency of Discharge | 96~99% @1C | |||||
| Standard Charge | Charge Voltage | 14.6±0.2V | ||||
| Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | |||||
| Charger Current | 20A | |||||
| Max. Charge Current | 100A | |||||
| Charge Cut-off Voltage | 15.6V±0.2V | |||||
| Standard Discharge | Continuous Current | 100A | ||||
| Max. Pulse Current | 300A(<10s) | |||||
| Discharge Cut-off Voltage | 10.5V | |||||
| Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity | ||||
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |||||
| Storage Temperature | IP56 | |||||
| Water Dust Resistance | IP56 | |||||
| Mechanical | Cell & Method | 26650 4S36P | ||||
| Plastic Case | ABS | |||||
| Dimensions (in./mm.) | 335*170*210mm Customized | |||||
| Weight (lbs./kg.) | 25kg | |||||
| Terminal | T11 | |||||
| Protocol (optional) | SMBus/RS485/RS232 | |||||
| SOC (optional) | ||||||
Company Features
1. MeriTech Power Co.,Ltd. has always devoted itself to the research, development and production of superior lithium battery low temperature . We have gained a considerable market share in overseas markets after years of active market exploration. We have built strong customer bases in North America, Australia, and Southeast Asia.
2. Our factory has conducted a rigorous production management system. This system provides a scientific production process control. This has only enabled us to control production costs but also increase efficiency.
3. Our factory offers an ideal production environment with a strong regulatory system, low energy costs, great talent pool, and high quality standards. We have a corporate culture of mutual respect, cross-collaboration, and inclusion, which enhances our operational excellence while making a positive impact in the lives of our customers and the communities we serve.
