MERITSUN new lifepo4 battery 12v 100ah series for house
1. MERITSUN lifepo4 batteries for sale is manufactured using the finest raw material, which is procured from some of the most trustworthy and certified vendors in the industry. Using LiFePO4 along with the integrated BMS, the product features overcharge and discharge protection
2. The application result shows that this product is of practical use. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
3. This product has a high-rate discharge capability. The resistance of contact face between electrodes and electrolyte is lowered to a certain level, which enhances its electric performance. Made of reliable chemical substances, the product is of superior safety
4. This product has a long service life. Its current collectors are well protected to prevent any liquid corrosion or rust. It is packed with high-quality and sturdy packages
5. This product can store energy reasonably well for a long time with low self-discharge. It will not be affected by outer elements such as temperature, moisture, vibration, shock, etc. The product is designed with a protection circuit which can totally ensure the safety of users
Electrical Characteristics | Nominal Voltage | 25.6V (24V) |
Nominal Capacity | 50Ah | |
Energy | 1280Wh | |
Internal Resistance | ≤200mΩ | |
Cycle Life | >4000 cycles @1C 80%DOD | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @1C | |
Standard Charge | Charge Voltage | 29.2±0.2V |
Charge Mode | 0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV) | |
Charger Current | 45A | |
Max. Charge Current | 50A | |
Charge Cut-off Voltage | 31.2V±0.2V | |
Standard Discharge | Continuous Current | 50A |
Max. Pulse Current | 100A(<10s) | |
Discharge Cut-off Voltage | 20V | |
Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | 3.2V25Ah 8S2P |
Plastic Case | ABS | |
Dimensions (in./mm.) | 330*173*220mm | |
Weight (lbs./kg.) | 13.5kg | |
Terminal | / | |
Protocol (optional) | / | |
SOC (optional) | / |
MeriTech is focusing on new energy, Global market changes of battery, Through market research to constant understand customers needs in order to build a perfect service network,Own many experienced engineers and technicians, to provide comprehensive, in-depth, quickly and attentive service for you. We could response your request immediately.
MeriTech Power Specialist will estimate your power needs, identify potential problem areas and recommend a cost-effective solution. What you'll get:
1. The global optimum acquisition price for any required hardware
2. Installation considerations
3. Ongoing support options
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MERITSUN has made a great success in improving the performance of lifepo4 battery 12v 100ah .
2. It is a fact that MERITSUN has been keeping the idea of lithium ion rechargeable battery first in mind since founded. Get price!
