MERITSUN low temperature lithium battery supply for car
Model:
LFP200-12.8, Bluetooth Battery
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Video Display
1. From the preliminary design stage of MERITSUN low temperature lithium ion to the finished product stage, a complete set of the inspection and auditing system is carried out to meet the industry standard for crafts products. The product is characterized by thermal performance
2. MeriTech Power Co.,Ltd. strongly adhere to the goal of quality first. Before shipment, the product will undergo 45 kinds of detailed tests
3. The product has good environmental adaptability. It is not easily affected by vibration, shock, bump, extrusion, dropping, and temperature. Strong reliability is one of the features of the product
4. The product has high power and high specific energy. All of its main raw materials including the electrolyte and positive and negative anodes feature high quality and purity. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity
5. This product has a long service life. Its current collectors are well protected to prevent any liquid corrosion or rust. The product is produced under the principle of environmental protection
Electrica Characteristics | Nominal Voltage | 12.8V | ||||
| Nominal Capacity | 100Ah | |||||
| Energy | 1280Wh | |||||
| Internal Resistance | ≤150mΩ | |||||
| Cycle Life | ≥4000 cycles @1C 100%DOD | |||||
| Months Self Discharge | <3% | |||||
| Efficiency of Charge | 100% @0.5C | |||||
| Efficiency of Discharge | 96~99% @1C | |||||
| Standard Charge | Charge Voltage | 14.6±0.2V | ||||
| Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | |||||
| Charger Current | 20A | |||||
| Max. Charge Current | 100A | |||||
| Charge Cut-off Voltage | 15.6V±0.2V | |||||
| Standard Discharge | Continuous Current | 100A | ||||
| Max. Pulse Current | 300A(<10s) | |||||
| Discharge Cut-off Voltage | 10.5V | |||||
| Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity | ||||
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |||||
| Storage Temperature | IP56 | |||||
| Water Dust Resistance | IP56 | |||||
| Mechanical | Cell & Method | 26650 4S36P | ||||
| Plastic Case | ABS | |||||
| Dimensions (in./mm.) | 335*170*210mm Customized | |||||
| Weight (lbs./kg.) | 25kg | |||||
| Terminal | T11 | |||||
| Protocol (optional) | SMBus/RS485/RS232 | |||||
| SOC (optional) | ||||||
Company Features
1. Depending on years of exploration, MeriTech Power Co.,Ltd. shows strong capabilities of designing and manufacturing low temperature lithium ion over other competitors. MeriTech Power Co.,Ltd. has made a modern manufacturing line with strict, serious and sincere attitude.
2. By innovating technology and optimizing service structure, MERITSUN can provide customers with one-stop solutions.
3. MeriTech Power Co.,Ltd. has a group of designers and skilled manufacturing staff. MERITSUN upholds the concept of the integration of low temperature charging lithium ion and lithium ion battery at low temperature together. Welcome to visit our factory!
