Company Advantages1. We make sure that the MERITSUN home battery system label contains all the necessary information, including the registration number, country of origin, and fabric composition. Strong reliability is one of the features of the product
2. This one is superior when measured against the standards of like kind. In other words, the best of fabric, materials, workmanship, construction, and fits as it has. - Said one of our customers. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
3. The product undergoes rigorous quality checks under the supervision of qualified professionals to ensure quality. The charge rate of the product is strong, shortening the charge time efficiently
4. Systematic quality control: it is the key control factors in the whole production process. From development to the shipment, the quality of this product is under the whole control of the quality team. It is produced in strict accordance with the UL standard
![MERITSUN long cycle life house power battery series for home appliances1 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
| Models | AI 3K | AI 5K |
| Battery |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3kWH | 5kWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO Battery
|
AC Output
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 22 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Multi-purpose Socket×2 |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| MPPT Range | 60V~115V |
Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan
|
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Load Match Mode |
![MERITSUN long cycle life house power battery series for home appliances1 12]()
![MERITSUN long cycle life house power battery series for home appliances1 13]()
![MERITSUN long cycle life house power battery series for home appliances1 14]()
![MERITSUN long cycle life house power battery series for home appliances1 15]()
![MERITSUN long cycle life house power battery series for home appliances1 16]()
![MERITSUN long cycle life house power battery series for home appliances1 17]()
![MERITSUN long cycle life house power battery series for home appliances1 18]()
![MERITSUN long cycle life house power battery series for home appliances1 19]()
![MERITSUN long cycle life house power battery series for home appliances1 20]()
Company Features1. Specializing in the R&D, design, production, and supply of home battery system , MeriTech Power Co.,Ltd. has become a dominant market player in China.
2. Our company has skilled and dedicated product developers and designers. Some of their specialties include rapid conceptualization, technical/control drawings, graphic design, visual brand identity, and product photography.
3. The permanent aim of MeriTech Power Co.,Ltd. would be to make top brands in the world battery for home use industry. Get price!
