Company Advantages1. MERITSUN home battery backup is carefully designed. It is an outcome with essential considerations such as spacing and insulation requirements, supply connections, component requirements, and performance test criteria. The product is produced under the principle of environmental protection
2. The fabric of this product contains no toxic chemicals and may inhale sleep or cause skin irritation. Using LiFePO4 along with the integrated BMS, the product features overcharge and discharge protection
3. Compared with the other similar products, home battery backup exhibited features like battery for home use . The charge rate of the product is strong, shortening the charge time efficiently
4. It is indicated that home battery backup has the features of battery for home use and ideal applied effect. Strong reliability is one of the features of the product
5. battery for home use is used for protection to control the home battery backup. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity
![MERITSUN long cycle life home battery backup series for picnic 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
| Models | AI 3K | AI 5K |
| Battery |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3kWH | 5kWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO Battery
|
AC Output
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 22 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Multi-purpose Socket×2 |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| MPPT Range | 60V~115V |
Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan
|
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Load Match Mode |
![MERITSUN long cycle life home battery backup series for picnic 12]()
![MERITSUN long cycle life home battery backup series for picnic 13]()
![MERITSUN long cycle life home battery backup series for picnic 14]()
![MERITSUN long cycle life home battery backup series for picnic 15]()
![MERITSUN long cycle life home battery backup series for picnic 16]()
![MERITSUN long cycle life home battery backup series for picnic 17]()
![MERITSUN long cycle life home battery backup series for picnic 18]()
![MERITSUN long cycle life home battery backup series for picnic 19]()
![MERITSUN long cycle life home battery backup series for picnic 20]()
Company Features1. MERITSUN enjoys great reputation among customers both home and abroad.
2. Our factory has a standard workshop that is built according to the stipulated requirements. The workshop has reasonable arranged production lines that guarantee smooth, ordered, and efficient production.
3. Instead of choosing the profit-driven strategies, our company insists on holding the strategy of promoting corporate social responsibility. In response to the ever-increasing environmental problems, we make sustainable plans for reducing water and air pollution, as well as energy saving. Inquire now!
