MERITSUN li ion battery cell manufacturer for solar
Model:
IFR18650 3.2V 1500mAh
Rated Voltage (V):
3.2
Rated Capacity (Ah):
1500mAh
Supply Ability:
500000 Pieces per Month
MOQ:
10
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Approx Dimension (mm):
18650
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Company Advantages
1. MERITSUN 3.7 volt rechargeable lithium ion battery is designed under the combination of various factors. They are lines, body proportion, style, color and texture, aesthetic sense, and others. It can be used within a wider temperature range from -20℃ to 65℃
2. The market response to the product is positive, which implies that the product will be more applied in the market. It can be widely applied in diverse areas ranging from small appliances and IT devices
3. It is smooth and soft. During the production process, the raising process is carried out to treat the surface of the fabric with sharp teeth, thereby lifting the surface fibers and imparting hairiness and softness. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
4. It is characterized by a precise dimension. Machined by CNC equipment, its sizes including length, width, height, and shape will be handled precisely to every detail. The product with a long service life can be used for more than 8 years
![]()
![]()
1. MERITSUN 3.7 volt rechargeable lithium ion battery is designed under the combination of various factors. They are lines, body proportion, style, color and texture, aesthetic sense, and others. It can be used within a wider temperature range from -20℃ to 65℃
2. The market response to the product is positive, which implies that the product will be more applied in the market. It can be widely applied in diverse areas ranging from small appliances and IT devices
3. It is smooth and soft. During the production process, the raising process is carried out to treat the surface of the fabric with sharp teeth, thereby lifting the surface fibers and imparting hairiness and softness. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
4. It is characterized by a precise dimension. Machined by CNC equipment, its sizes including length, width, height, and shape will be handled precisely to every detail. The product with a long service life can be used for more than 8 years
For More Details, Please Contact US !
| NO. | Items | Parameter | Remarks |
| 1 | Rated Capacity | 1500mAh | Discharge:0.2C Cut-off voltage:3.0V |
| Minimum Capacity | 1450mAh | ||
| 2 | Energy | 4.8Wh | |
| 3 | Nominal Voltage | 3.2V | |
| 4 | Open Voltage | ≥3.2V | |
| 5 | Load Voltage | ≥ 3.2V | 10Ω |
| 6 | Cycle Life | ≥2000 times | |
| 7 | Internal Impedance | ≤50mΩ | AC 1KHz after 50% charge |
| 8 | Charge voltage | 3.65V | |
| 9 | Standard charge current | 300mA | |
| 10 | Max charge current | 750mA | |
| 11 | Standard discharge current | 1500mA | |
| 12 | Pulse Discharge current | 10A (5S) | |
| 13 | Discharge cut-off voltage | 2.5V | |
| 14 | Operating Temperature | 0~+55℃ | Charge |
| -20~+60℃ | Discharge | ||
| 15 | Storage temperature for a long time | -20~25℃ | |
| 16 | Weight | 42±1g | |
| 17 | Dimensions-Diameter | 18.3±0.2mm | |
| Dimensions-Height | 65.3±0.2mm |
The Lithium Battery Cell Characteristic Curve , Please Refer To:
The Battery Advantages and Cells Consistency Countermeasures for
18650 Battery, Lithium Battery, Lipo Battery, Li-ion battery, LiFePO4 Battery,
Rechargeable Lithium ion Battery, Lithium Polymer Battery,
Lithium iron Phosphate Battery
The Battery Safety Assurance and Low Self Discharge for 18650 Battery, Lithium Battery,
Lipo Battery, Li-ion battery, LiFePO4 Battery, Rechargeable Lithium ion Battery,
Lithium Polymer Battery, Lithium iron Phosphate Battery
More Lithium Battery Cells Model Reference:
