Company Advantages1. The manufacture of MERITSUN lithium ion home battery is exquisite. Its components and parts have been sophisticatedly fabricated by abrasive machining, CNC machining, drilling, honing, etc. It is of extremely low self-discharge rate and can be left unused for a longer time
2. house power battery is highly recommended by lithium ion home battery according to rich experiences. It is produced in strict accordance with the UL standard
3. The product is less likely to leak. It is finely sealed with good materials which effectively hide its electrolyte inside. The product is characterized by thermal performance
4. A low self-discharge rate is one of its biggest selling points. Its anode and cathode materials, as well as the electrolyte types, features high purity and quality, which makes it less vulnerable to self-discharge. It is packed with high-quality and sturdy packages
5. It can be regarded as a green source of energy. All of its metal ingredients, including cadmium and mercury, as well as the electrolyte, poses no harm to the environment. The product with a long service life can be used for more than 8 years
![MERITSUN house power battery factory direct supply for house 11]()
Feature
1.Built in Inverter and Smart BMS,Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
![MERITSUN house power battery factory direct supply for house 12]()
| Models | Nominal Voltage | 48V |
| Battery |
|
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3KWH | 5KWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO Battery |
AC Output
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 22 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Multi-purpose Socket×2 |
| AC Input Voltage Range | 170~280Vac |
| Max AC Charge Current(Battery) | 40A | 60A |
PV Input
|
| Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| MPPT Range | 60V~115V |
| Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
|
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan |
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
|
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Solar—Battery—Utility |
![MERITSUN house power battery factory direct supply for house 13]()
![MERITSUN house power battery factory direct supply for house 14]()
![MERITSUN house power battery factory direct supply for house 15]()
![MERITSUN house power battery factory direct supply for house 16]()
![MERITSUN house power battery factory direct supply for house 17]()
![MERITSUN house power battery factory direct supply for house 18]()
![MERITSUN house power battery factory direct supply for house 19]()
Company Features1. MeriTech Power Co.,Ltd. is one of China’s leading providers of house power battery . We specialize in development, design, and manufacture.
2. The high-quality home battery backup indicates that MERITSUN has broken the barriers to technological innovation.
3. The service assurance is also very important in MeriTech Power Co.,Ltd.. Inquire!
