Company Advantages1. Manufacturing MERITSUN home power battery requires different facilities. It is processed under stamping, coating, painting and drying equipment with high performance and high efficiency. The weight of the product is about 40% of the weight of a comparable lead-acid battery
2. house power battery is manufactured based on advanced technology. Besides, it is charged three times and discharged twice to activate the battery before being shipped out of the factory. The balance, consistency and stability of the battery can be ensured.
3. The product has high power and high specific energy. All of its main raw materials including the electrolyte and positive and negative anodes feature high quality and purity. It is of extremely low self-discharge rate and can be left unused for a longer time
4. A low self-discharge rate is one of its biggest selling points. Its anode and cathode materials, as well as the electrolyte types, features high purity and quality, which makes it less vulnerable to self-discharge. It can be used within a wider temperature range from -20℃ to 65℃
5. This product has a high-rate discharge capability. The resistance of contact face between electrodes and electrolyte is lowered to a certain level, which enhances its electric performance. Supported by the lead-acid battery, it has a high discharge rate while maintaining high energy capacity
![MERITSUN house power battery factory direct supply for home appliances2 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
![MERITSUN house power battery factory direct supply for home appliances2 12]()
| Models | AI 3K | AI 5K |
| Models |
|
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3KWH | 5KWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO4 Battery |
| AC Output |
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 13.7 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Output Type |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
| Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
|
| Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
|
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan |
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
|
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Solar—Battery—Utility |
![MERITSUN house power battery factory direct supply for home appliances2 13]()
![MERITSUN house power battery factory direct supply for home appliances2 14]()
![MERITSUN house power battery factory direct supply for home appliances2 15]()
![MERITSUN house power battery factory direct supply for home appliances2 16]()
![MERITSUN house power battery factory direct supply for home appliances2 17]()
![MERITSUN house power battery factory direct supply for home appliances2 18]()
![MERITSUN house power battery factory direct supply for home appliances2 19]()
Company Features1. As a professional house power battery supplier, MERITSUN also specializes in offering one-stop solutions.
2. The factory production lines of MeriTech Power Co.,Ltd. are all run under the international standard.
3. At the heart of our company are employees and values. We encourage our valuable and talented team to work for the company's goals based on quality, delivery, and service. Get more info!
