Company Advantages1. home battery backup in various colors, shapes help it to be applied widely without any trouble. It is produced in strict accordance with the UL standard
2. People don't have to worry that this product will suffer from aging issues and it can run in harsh conditions. Using LiFePO4 along with the integrated BMS, the product features overcharge and discharge protection
3. The product has good temperature adaptability. It can work under a wide range of temperature and it has been optimized with high-temperature performance. It can be used within a wider temperature range from -20℃ to 65℃
4. The product has a relatively wide range of working temperature. It can work normally under high and cold temperature without influence on its electricity performance. Before shipment, the product will undergo 45 kinds of detailed tests
5. The product features high specific energy. The electrode materials can release as much as electricity when they have electrode reaction. The product is produced under the principle of environmental protection
![MERITSUN energy saving home battery backup manufacturer for home appliances2 11]()
Feature
1.Built in Inverter and Smart BMS.Save installation time and labor.
2.WiFi App Management Optional.
3.Longer Cycle Life:6000 Cycle Life @80%DOD.
4.Easy to move with wheels.Compact and portable design,indoor and outdoor workable.
5.Triple input:Solar energy charging;Utility Grid charging and Diesel Engine charging.
| Models | AI 3K | AI 5K |
| Battery |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [V] | 44.8~57.6 |
| Capacity | 3kWH | 5kWH |
| Max.discharge rate | 0.7C | 0.7C |
| Max.charge rate | 0.5C | 0.5C |
| Battery Type | LiFePO Battery
|
AC Output
|
| Rated Power | 3000VA | 5000VA |
| Overload Capacity | 120% (5s) |
| 200% (100ms) |
| Output Voltage | 230Vac±2% |
| Output Current | 13.7 A | 22 A |
| Rated Frequency | 50/60Hz |
| VTHD | 3% |
| Transfer Time | ＜10ms |
| Output Wave | Pure Sine Wave |
| Output Type | Multi-purpose Socket×2 |
| AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50Hz/60Hz |
Max AC Charge Current(Battery) | 40A | 60A |
| PV Input |
Max. PV Power(Recommended) | 3000w | 4000w |
| Max. PV Voltage | 145V |
| MPPT Range | 60V~115V |
Max PV Charge Current(Battery) | 60A | 80A |
| Operating Conditions |
| Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan
|
| Weight [kg] | 42 | 60 |
| Dimension [W x H x D, mm] | 700*580*230 | 700*580*230 |
| Enclosure Protection Rating | IP31 |
| Communication | Wifi(Remote) |
| Work Mode |
| Solar First | Solar and UPS |
| Utility First | UPS and Backup |
| Solar—Battery—Utility | Load Match Mode |
![MERITSUN energy saving home battery backup manufacturer for home appliances2 12]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 13]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 14]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 15]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 16]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 17]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 18]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 19]()
![MERITSUN energy saving home battery backup manufacturer for home appliances2 20]()
Company Features1. MeriTech Power Co.,Ltd. works with famous brands with resource advantages.
2. Our business operates successfully in China. We also expand globally to many regions such as Europe, Asia, the Middle East, and North America and establish a solid customer base.
3. We promise all of our business activities are conform to the legal statutes of China. We'll never produce unlicensed products or infringe copyrights.
