MERITSUN best low temperature lithium battery suppliers for streetlight
Model:
LFP200-12.8, Bluetooth Battery
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Video Display
Product Details
Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system.'s battery manufacturing companies is processed based on the latest technology. It has excellent performances in the following details.Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system.'s battery manufacturing companies is highly competitive in the domestic and foreign markets.
Application Scope
With wide application, battery solutions can be used in the following aspects.Established in 1999, MeriTech has 18 years of experience in providing solutions services in energy storage application industry. We dedicated to designing and manufacturing of LiFePO4 and lithium cells and integrated battery packs for energy system. is dedicated to providing professional, efficient and economical solutions for customers, so as to meet their needs to the greatest extent.
1. Manufacturing MERITSUN low temp lithium battery requires different facilities. It is processed under stamping, coating, painting and drying equipment with high performance and high efficiency.
2. MERITSUN makes targeted improvements, preventing quality problems.
3. It quality is demonstrated during a rigorous audit process.
4. Our low temperature lithium battery covers high technology of low temp lithium battery and li-ion battery at low temperature.
5. MeriTech Power Co.,Ltd. will conduct a comprehensive survey for customer’s demands, such as structure, material, usage and so on.
Electrica Characteristics | Nominal Voltage | 12.8V | ||||
| Nominal Capacity | 100Ah | |||||
| Energy | 1280Wh | |||||
| Internal Resistance | ≤150mΩ | |||||
| Cycle Life | ≥4000 cycles @1C 100%DOD | |||||
| Months Self Discharge | <3% | |||||
| Efficiency of Charge | 100% @0.5C | |||||
| Efficiency of Discharge | 96~99% @1C | |||||
| Standard Charge | Charge Voltage | 14.6±0.2V | ||||
| Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | |||||
| Charger Current | 20A | |||||
| Max. Charge Current | 100A | |||||
| Charge Cut-off Voltage | 15.6V±0.2V | |||||
| Standard Discharge | Continuous Current | 100A | ||||
| Max. Pulse Current | 300A(<10s) | |||||
| Discharge Cut-off Voltage | 10.5V | |||||
| Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity | ||||
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |||||
| Storage Temperature | IP56 | |||||
| Water Dust Resistance | IP56 | |||||
| Mechanical | Cell & Method | 26650 4S36P | ||||
| Plastic Case | ABS | |||||
| Dimensions (in./mm.) | 335*170*210mm Customized | |||||
| Weight (lbs./kg.) | 25kg | |||||
| Terminal | T11 | |||||
| Protocol (optional) | SMBus/RS485/RS232 | |||||
| SOC (optional) | ||||||
Company Features
1. MeriTech Power Co.,Ltd. is a vanguard enterprise in the low temperature lithium battery industry in China.
2. We have a strong customer base spread over all over the world. At present, we have relatively stable overseas markets because we have been continuously improving technical base and innovation ability.
3. We want to become even more a brand that people love - A future-proof and high-quality company with strong premium consumer and business relations. We bear social responsibilities. We are dedicated to performing at or above all industry health, safety, and environmental laws and regulations. Our goal is to be an active and responsible leader, committed to the sustainable development of global markets, and to promote responsible practices in our industry. Please contact us!
