latest lithium battery with bluetooth supply for boat
1. MERITSUN 12v 100ah lithium ion battery is made of professional material. This kind of material has a high gain performance for applications with a high ambient light intrusion. Strong reliability is one of the features of the product
2. MeriTech Power Co.,Ltd. has strong reaction ability and new product development ability in lithium battery with bluetooth field. It is very easy to use
3. The product has a long service life. It is not likely to be affected by excessive operating temperatures, overload, and deep discharge. It is produced in strict accordance with the UL standard
4. The product is environmentally friendly. Many of the materials within these batteries, such as lead, plastic, and metal, are recyclable. The weight of the product is about 40% of the weight of a comparable lead-acid battery
Electrical Characteristics | Nominal Voltage | 25.6V (24V) |
Nominal Capacity | 100Ah | |
Energy | 2560Wh | |
Internal Resistance | ≤200mΩ | |
Cycle Life | >4000 cycles | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @1C | |
Standard Charge | Charge Voltage | 29.2±0.2V |
Charge Mode | 0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV) | |
Charger Current | 49A | |
Max. Charge Current | 50A | |
Charge Cut-off Voltage | 31.2V±0.2V | |
Standard Discharge | Continuous Current | 50A |
Max. Pulse Current | 100A(<10s) | |
Discharge Cut-off Voltage | 20V | |
Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | 3.2V10Ah 8S10P |
Plastic Case | ABS | |
Dimensions (in./mm.) | 522*240*224mm | |
Weight (lbs./kg.) | 30.5kg | |
Terminal | / | |
Protocol (optional) | / | |
SOC (optional) | / |
MeriTech is focusing on new energy, Global market changes of battery, Through market research to constant understand customers needs in order to build a perfect service network,Own many experienced engineers and technicians, to provide comprehensive, in-depth, quickly and attentive service for you. We could response your request immediately.
MeriTech Power Specialist will estimate your power needs, identify potential problem areas and recommend a cost-effective solution. What you'll get:
1. The global optimum acquisition price for any required hardware
2. Installation considerations
3. Ongoing support options
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. is very professional in manufacturing lithium battery with bluetooth, which is reliable among customers.
2. The factory has implemented a strict production control system for years. This system stipulates requirements for workmanship, energy resources utilization, and waste treatment, which enables the factory to regulate all of the production processes.
3. Our mission is to deliver effective and innovative business solutions in a data-centric world. We drive long term success for our clients and partners by listening and challenging conventional thinking. Contact us!
