icr lipo 37v OEM li ion battery cell MERITSUN
1. The li ion battery cell facility can lithium ion battery cells and you can specify 3.7 volt rechargeable lithium ion battery.OEM and ODM services are available for us
2. It is of great importance for MERITSUN to provide exquisite customer service. We use high purity raw material to ensure low self discharge rate
3. We mainly focus on alternative green energy from Lead Acid battery. Developed from industrial raw material the offered 18650 battery cell,18650 rechargeable lithium ion battery features clean lines and assurance of long lasting performance.
4. We have specialized expertise for providing an elegant variety of high drain battery in the market. Our diversified products owns a wider applications
5. MeriTech is committed to being the market leader in the green energy industry. 18650 high drain battery,lithium battery suppliers is well equipped with excellent properties such as 18650 lithium rechargeable battery.
| NO. | Items | Parameter | Remarks |
| 1 | Rated Capacity | 2400mAh | Discharge:0.2C Cut-off voltage:3.0V |
| Minimum Capacity | 2350mAh | ||
| 2 | Energy | 8.88Wh | |
| 3 | Nominal Voltage | 3.7V | |
| 4 | Open Voltage | ≥3.85V | |
| 5 | Load Voltage | ≥ 3.6V | 10Ω |
| 6 | Cycle Life | 500~1000 times | |
| 7 | Internal Impedance | ≤50mΩ | AC 1KHz after 50% charge |
| 8 | Charge voltage | 4.2V | |
| 9 | Standard charge current | 480mA | |
| 10 | Max charge current | 2400mA | |
| 11 | Standard discharge current | 480mA | |
| 12 | Max Discharge current | 3600mA | |
| 13 | Discharge cut-off voltage | 3.0V | |
| 14 | Operating Temperature | 0~+45℃ | Charge |
| -20~+60℃ | Discharge | ||
| 15 | Storage temperature for a long time | -20~25℃ | |
| 16 | Weight | 45±1g | |
| 17 | Dimensions-Diameter | 18.3±0.2mm | |
| Dimensions-Height | 65.3±0.2mm |
