Hot 32v li ion battery cell drain cell MERITSUN Brand
Model:
ICR18650 3.7V 2400mAh
Rated Voltage (V):
3.7
Rated Capacity (Ah):
2400mAh
Supply Ability:
500000 Pieces per Month
MOQ:
10
Payment:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, WeChat pay, Paypal
Approx Dimension (mm):
18650
Certificate:
ISO, UL, CE, RoHS, UN38.3, TLC, TUV, IEC, and so on
Please:
click the "Inquire Online" button below, you will get the best design solution for FREE! and The Best offer.
Company Advantages
1. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises. As one of the unique feature, lithium ion battery cells successfully makes 3.7 volt rechargeable lithium ion battery more popular among customers. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises
2. MeriTech Power Co.,Ltd., well-known for its superior quality, will provide first-class service. There are many experienced engineers and technicians in our company
3. We are dedicated to manufacturing and designing LiFePO4 and lithium cells, MERITSUN Has Helped Ourselves As One Of The Leading Brand In This Field Of li ion battery cell, 18650 rechargeable lithium ion battery.
4. 18650 battery cell have always found a traditional use in the lithium battery suppliers industries. Focusing on smart energy project, we are an innovation pioneer
5. Products by MeriTech Power Co.,Ltd. are of excellent high drain battery performance. Our products are certified to ISO, CE, ROHS, TLC, TUV, IEC, and so on
![]()
![]()
1. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises. As one of the unique feature, lithium ion battery cells successfully makes 3.7 volt rechargeable lithium ion battery more popular among customers. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises
2. MeriTech Power Co.,Ltd., well-known for its superior quality, will provide first-class service. There are many experienced engineers and technicians in our company
3. We are dedicated to manufacturing and designing LiFePO4 and lithium cells, MERITSUN Has Helped Ourselves As One Of The Leading Brand In This Field Of li ion battery cell, 18650 rechargeable lithium ion battery.
4. 18650 battery cell have always found a traditional use in the lithium battery suppliers industries. Focusing on smart energy project, we are an innovation pioneer
5. Products by MeriTech Power Co.,Ltd. are of excellent high drain battery performance. Our products are certified to ISO, CE, ROHS, TLC, TUV, IEC, and so on
Product Description
/ For more details, please contact us！
| NO. | Items | Parameter | Remarks |
| 1 | Rated Capacity | 2400mAh | Discharge:0.2C Cut-off voltage:3.0V |
| Minimum Capacity | 2350mAh | ||
| 2 | Energy | 8.88Wh | |
| 3 | Nominal Voltage | 3.7V | |
| 4 | Open Voltage | ≥3.85V | |
| 5 | Load Voltage | ≥ 3.6V | 10Ω |
| 6 | Cycle Life | 500~1000 times | |
| 7 | Internal Impedance | ≤50mΩ | AC 1KHz after 50% charge |
| 8 | Charge voltage | 4.2V | |
| 9 | Standard charge current | 480mA | |
| 10 | Max charge current | 2400mA | |
| 11 | Standard discharge current | 480mA | |
| 12 | Max Discharge current | 3600mA | |
| 13 | Discharge cut-off voltage | 3.0V | |
| 14 | Operating Temperature | 0~+45℃ | Charge |
| -20~+60℃ | Discharge | ||
| 15 | Storage temperature for a long time | -20~25℃ | |
| 16 | Weight | 45±1g | |
| 17 | Dimensions-Diameter | 18.3±0.2mm | |
| Dimensions-Height | 65.3±0.2mm |
The Lithium Battery Cell Characteristic Curve , Please Refer To:
The Battery Advantages and Cells Consistency Countermeasures for
18650 Battery, Lithium Battery, Lipo Battery, Li-ion battery, LiFePO4 Battery,
Rechargeable Lithium ion Battery, Lithium Polymer Battery,
Lithium iron Phosphate Battery
The Battery Safety Assurance and Low Self Discharge for 18650 Battery, Lithium Battery,
Lipo Battery, Li-ion battery, LiFePO4 Battery, Rechargeable Lithium ion Battery,
Lithium Polymer Battery, Lithium iron Phosphate Battery
More Lithium Battery Cells Model Reference:
