gel opzv deep opzv battery tubular MERITSUN Brand
1. We mainly focus on alternative green energy from Lead Acid battery. As one of the unique feature, vrla gel battery successfully makes opzs batterie more popular among customers. We mainly focus on alternative green energy from Lead Acid battery
2. MeriTech Power Co.,Ltd., well-known for its superior quality, will provide first-class service. There are many successful cases with our products
3. gel batteries for sale releases the burden of our engineers who are responsible for the maintaince of opzv battery. There are many experienced engineers and technicians in our company
❈ Product Features
★ General Features：
◪1. Completely sealing throughout the batteries life.
◪2. Service life up to 18-20 years in continuous float operation down to approx 80% capacity.
◪3. Gel electrolyte.
◪4. Low gassing thanks to antimony-free alloy and internal oxygen recombination.
◪5. Minimum space required and room requirements are minimal e.g. no washing facilities needed, ventilation requirements are minimal.
◪6. Easy to move and handle.
◪7. Easy install using cable connectors with insulated terminal covers.
◪8. Ready for immediate use without further commissioning work.
◪9. Can be supplied as a standard vertical installation or by special request, for a horizontal installation.
◪10. Very low self-discharge<50% of rated capacity in 2 years at 20 ℃ ambient temperature.
◪11. High cyclic ability over 600 cycles when discharged at 10 hour rate to an end voltage of 1.8Volt/cell at 20℃ .
◪12. Deep discharge protected, a load can be connected to the battery for up to 4 weeks.
◪13. No internal short circuits possible due to the gel structure.
◪14. No acid stratification, so no equalizing charge necessary.
❈ Typical Applications
| Telecommunications | Large UPS and computer back-up | Railway signalling |
| Emergency lighting systems | Radio and cellular telephone relay stations | Standby power |
| Process and control engineering | Maritime standby power on ships and ashore | Buoy lighting |
| Power stations, Conventional power stations, alternative power (solar, wind) | ||
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
OPzV200-2 | 2 | 200 | 103 | 4.06 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 18.0 | 39.7 | T11 |
OPzV250-2 | 2 | 250 | 124 | 4.88 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 22.0 | 48.5 | T11 |
OPzV300-2 | 2 | 300 | 145 | 5.71 | 206 | 8.11 | 355 | 13.98 | 390 | 15.35 | 26.0 | 57.3 | T11 |
OPzV350-2 | 2 | 350 | 124 | 4.88 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 29.0 | 63.9 | T11 |
OPzV420-2 | 2 | 420 | 145 | 5.71 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 34.0 | 74.9 | T11 |
OPzV490-2 | 2 | 490 | 166 | 6.54 | 206 | 8.11 | 471 | 18.54 | 506 | 19.92 | 39.0 | 86.0 | T11 |
OPzV600-2 | 2 | 600 | 145 | 5.71 | 206 | 8.11 | 646 | 25.43 | 681 | 26.81 | 46.0 | 101.4 | T11 |
OPzV800-2 | 2 | 800 | 191 | 7.52 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 64.5 | 142.2 | T11 |
OPzV1000-2 | 2 | 1000 | 233 | 9.17 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 78.5 | 173.0 | T11 |
OPzV1200-2 | 2 | 1200 | 275 | 10.83 | 210 | 8.27 | 646 | 25.43 | 681 | 26.81 | 93.0 | 205.0 | T11 |
OPzV1500-2 | 2 | 1500 | 275 | 10.83 | 210 | 8.27 | 796 | 31.34 | 831 | 32.72 | 115.0 | 253.5 | T11 |
OPzV2000-2 | 2 | 2000 | 399 | 15.71 | 214 | 8.43 | 772 | 30.39 | 807 | 31.77 | 155.0 | 341.6 | T11 |
OPzV2500-2 | 2 | 2500 | 487 | 19.17 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 196.0 | 432.0 | T11 |
OPzV3000-2 | 2 | 3000 | 576 | 22.68 | 212 | 8.35 | 772 | 30.39 | 807 | 31.77 | 232.0 | 511.3 | T11 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
