front terminal opzs flooded MERITSUN Brand opzv battery supplier
1. We are specialized in offering our clients an excellent array of opzv battery.
2. MeriTech Power Co.,Ltd. is familiar with the sales network in opzs battery area. Established in 1999, we have 18 years experience in energy power industry
3. "Technology, R&D, Innovation, and Breakthrough " are what set us apart from other enterprises. agm vrla battery,vrla gel battery has been considered to be opzs batterie with obvious quality and wide development prospects.
❈ Product Features
★ General Features：
◪1. Specifically ideal for 19 inch or 23 inch power cabinets
◪2. Front terminals make the installation, maintenance and supervision easy
◪3. Shield designs protect terminals from short circuit and show good appearance
◪4. Unique vent valve design: reduce water losing and prevent air/spark going inside
◪5. Thick plates, special formula of paste and plate making process for a long service life
◪6. ABS material: increase the strength of battery container (Flame-retardant ABS is optional)
❈ Typical Applications
| For standard 19 inch or 23 inch power cabinets | Power station systems | UPS, standby power supply |
| Network connection equipment of communication system | Power system of special network or local area network | |
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
GF40-12 | 12 | 40 | 274 | 10.79 | 105 | 4.13 | 220 | 8.66 | 220 | 8.66 | 13.0 | 28.7 | T6 |
GF50-12 | 12 | 50 | 390 | 15.35 | 107 | 4.21 | 200 | 7.87 | 200 | 7.87 | 18.5 | 40.8 | T6 |
GF70-12 | 12 | 70 | 564 | 22.20 | 114 | 4.49 | 187 | 7.36 | 187 | 7.36 | 25.0 | 55.1 | T6 |
GF75-12 | 12 | 75 | 564 | 22.20 | 114 | 4.49 | 187 | 7.36 | 187 | 7.36 | 26.0 | 57.3 | T6 |
GF90-12 | 12 | 90 | 508 | 20.00 | 110 | 4.33 | 239 | 9.41 | 239 | 9.41 | 31.0 | 68.3 | T13 |
GF92-12 | 12 | 92 | 396 | 15.59 | 111 | 4.37 | 285 | 11.22 | 285 | 11.22 | 29.5 | 65.0 | T6 |
GF100-12A | 12 | 100 | 396 | 15.59 | 111 | 4.37 | 285 | 11.22 | 285 | 11.22 | 33.0 | 72.8 | T6 |
GF100-12B | 12 | 100 | 520 | 20.47 | 107 | 4.21 | 263 | 10.35 | 263 | 10.35 | 33.0 | 72.8 | T6 |
GF120-12 | 12 | 120 | 520 | 20.47 | 107 | 4.21 | 263 | 10.35 | 263 | 10.35 | 39.5 | 87.1 | T6 |
GF125-12 | 12 | 125 | 551 | 21.69 | 110 | 4.33 | 287 | 11.30 | 287 | 11.30 | 40.5 | 89.3 | T6 |
GF150-12 | 12 | 150 | 558 | 21.97 | 125 | 4.92 | 283 | 11.14 | 283 | 11.14 | 48.0 | 105.8 | T6 |
GF180-12 | 12 | 180 | 561 | 22.09 | 125 | 4.92 | 316 | 12.44 | 316 | 12.44 | 52.0 | 114.6 | T6 |
GF200-12 | 12 | 200 | 550 | 21.65 | 125 | 4.92 | 330 | 12.99 | 330 | 12.99 | 62.0 | 136.7 | T6 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MERITSUN has gained its popularity all over the world.
2. MeriTech Power Co.,Ltd.'s forward-looking technology helps its customers stay ahead of the industry.
3. MERITSUN Battery Solution offers quality opzv battery at the economical price. Inquire now!
