custom lithium battery manufacturers series for house
1. The creation of MERITSUN lifepo4 48v 100ah battery strictly meets the requirements of European safety standards including EN standards and norms, REACH, TüV, FSC, and Oeko-Tex. The product is produced under the principle of environmental protection
2. With this product, people can stay in a quiet tranquil environment. Because there will not be noises made by annoying flickering. Made of reliable chemical substances, the product is of superior safety
3. This product possesses a rigid skeleton because of its original function. It is designed for a life in a marine environment and is manufactured accordingly. It can be used within a wider temperature range from -20℃ to 65℃
Electrical Characteristics | Nominal Voltage | 12.8V (12V) |
Nominal Capacity | 100Ah | |
Energy | 1280Wh | |
Internal Resistance | ≤90mΩ | |
Cycle Life | >4000 cycles | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @1C | |
Standard Charge | Charge Voltage | 14.6±0.2V |
Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | |
Charger Current | 40A | |
Max. Charge Current | 70A | |
Charge Cut-off Voltage | 15.6V±0.2V | |
Standard Discharge | Continuous Current | 70A |
Max. Pulse Current | 100A(<10s) | |
Discharge Cut-off Voltage | 10V | |
Environmental | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
Water Dust Resistance | IP55 | |
Mechanical | Cell & Method | 3.2V25Ah 4S4P |
Plastic Case | ABS | |
Dimensions (in./mm.) | 330*173*220mm | |
Weight (lbs./kg.) | 13.5kg | |
Terminal | / | |
Protocol (optional) | / | |
LCD (optional) | Yes |
MeriTech is focusing on new energy, Global market changes of battery, Through market research to constant understand customers needs in order to build a perfect service network,Own many experienced engineers and technicians, to provide comprehensive, in-depth, quickly and attentive service for you. We could response your request immediately.
MeriTech Power Specialist will estimate your power needs, identify potential problem areas and recommend a cost-effective solution. What you'll get:
1. The global optimum acquisition price for any required hardware
2. Installation considerations
3. Ongoing support options
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. is a notable lithium battery manufacturers exporter. The factory runs under the guideline of the stringent ISO 9001 quality management system. This system is approved by the Certification and Accreditation Administration of the People’s Republic of China (CNAT), which is a strong assurance for our product quality.
2. We have a team of development and research members. Leveraging their years of developing experience, they work to develop innovative products per market trends and also constantly upgrade the form of these products.
3. We have modern production lines. These lines operate strictly under the scientific quality management system. This system has guaranteed quality ranging from raw materials to the final finished products. MeriTech Power Co.,Ltd. has been consistent for many years, providing integrity services to every customer. Inquiry!
